VIAP600-Ku Band 0.6m Virtuial Image Phased Array Antenna

Product Details VIPA600 is a new launched VIPA virtual image ku bandPhased Array Systemwhich is equivalent to 0.6m with separate receive and transmit structure, electromagenetism reflector that integrated that integrates shift phase and radiation phase. Phased controll is realised by electromagnetic wave to ensure high gain and wide-angle beam sacnning as well as carrier stable tracking the target satellite in motion.

Features1)One dimensional plane rotates realizes the two dimensional space scan.
2)Scan range ±60°
3)Low profile,high gain,high efficient

ApplicaitonTelecommunications, government emergency, enterprise, environment and territory, transportation, disasters and relief.

Specification

MODEL	VIPA600
Stabilization	6 axis stable tracking
Antenna Type	VIPA
Dimension	1780mm（L）×780mm（W）×98mm（H）
Weight	68kg
Frequency Range	RX：12.2～12.75GHz TX：14.00～14.50GHz
Gain	Rx≥31.6dBi（12.5GHz）@30°EL Rx≥35.1dBi（12.5GHz）@90°EA Tx≥32.8dBi（14.25GHz）@30°EL Tx≥36.3dBi（14.25GHz）@90°EA
Polarization	Linear
Cross Pol Isolation	＞35dB
Antenna Motion Range	Azimuth：360°Continuous rotation	Elevation：30°～90°
Carrier Motion Range	Roll： -30°～30°, period 8s
	Pitch： -30°～30°, period 8s
	Yaw： 40°/s
Track Mode	Full space pre -scanning location track
Tracking Accuracy	0.2°RMS
Initial Acquisition	≤120s
Re-Acquisition	≤2s
Input Power	AC220V 50Hz, standard power consumption 180W
Operating Temperature	-40℃～65℃
