A60-0.6m ka band Marine Antenna design for Chinasat-16

Download Send E-mail

Product Details

Features1) Automatically collect and output carrier position and attitude information
2) Storage of more than 10 satellite position parameter
3) Terminal One-key start, antenna tracking the satellite automatically
4) Polarization direction automatically adjust
5) Power-down memory and protection
6) Device detection and status checking
7) Power-on self test and fault alarming

ApplicaitonContainer vessel, dry bulk vessel, cruise ships, LPG/LNG, chemical vessel, multi-purpose ship, roll-on ship, oil tanker, Marine engineering vessel.

Specification

MODEL	A60
Stabilization	3 axis stable and 4 axis tracking
Reflector	Φ600mm
Dimension （Diameter×Height）	720mm×800mm
Weight	50kg
Frequency Range	RX：18.70～20.20GHz
Frequency Range	TX：29.00～30.00GHz
Type	Ring focus
Gain	RX：39.10dBi@19.45GHz
Gain	TX：42.70dBi@29.50GHz
Axial ratio	≤1.5
Polarization	Circular
Tracking Accuracy	≤0.2°RMS
Carrier Motion Range	Roll：-30°~30°
Carrier Motion Range	Pitch：-30°~30°
Antenna Motion Range	Azimuth：360°continuous rotation
	Elevation：-5°～110°
	Roll: -30°～30°
	Polarization: LHCP/RHCP
Initial Acquisition time	≤180s
Tracking mode	INS measurement and carrier tracking
Input Power	DC24V 50Hz peak power consumption 150W （BUC excluded）
Operating Temperature	-20℃～60℃
