Product Details GA450 is the satellite communication system designed for fixed wing aircraft. The system can improve the communicaiton support capabilities efficiently and keep communication of the aircraft in the high sky. It has the functions of real time video back , IP telephone call and broadband internet access, which made up for the shortage of demestic satellite communication equipment in general aviation.
|
MODEL |
GA450 |
|
Dimension (diameter*height) |
Φ870mm×315mm |
|
weight |
≤39.5kg |
|
Frequency range |
RX：10.95～12.75GHz TX：13.75～14.50GHz |
|
Type AMIP selectable by A791 |
Linear VP/HP |
|
Receive G/T(pitch 10°） |
11.54dB/K @12.25GHz（Normal temperature@27℃, LNB noise factor @0.9dB ,Radome excluded） |
|
transmit EIRP(dBW) |
48.5dBW@14.25GHz（40W BUC excluded） |
|
RF INPUT（TX） |
13.75-14.5GHz，SMA 50Ω |
|
RF OUTPUT（RX） |
950-2150MHz，TNC 50Ω |
|
Cross pollsolation |
≥30dB |
|
Power consumption |
100W(average) 40W BUC excluded |
|
Azimuth range |
360°continuous rotation |
|
Pitch range |
0°～90°(80°performance reach the standard） |
|
AZ/EI Velocity |
＞60°/s |
|
AZ/EI acceleration |
＞100°/s² |
|
Tracking accuracy |
≤0.2°RMS |
|
DC power |
DC18~32V |
|
Operating temperature |
-55℃ ~ +70℃ |
|
altitude |
16800Meters(55000Feet) |
