Product Details
SATPRO Series Maritime Satellite Communication System is designed with All-in-One highly integrated structure that integrate BUC, ACU and Modem inside the radome. The antenna is structure with economical and reliable reflector which guarantees the mechanical performance and small volume, suitable for medium and small sized ships as well as to reduce the communication cost.
2) built-in INS
3) modular design
4) simplified system structure
5) easy to operate
6) remote data monitoring
|
MODEL |
M80 |
|
Stabilization |
3 axis stable and 4 axis tracking |
|
Reflector |
Φ800mm |
|
Dimension （Diameter×Height） |
970mm×1020mm |
|
Weight |
≤55kg |
|
Frequency Range |
RX：10.70～12.75GHz |
|
TX：13.75～14.50GHz |
|
|
Gain |
RX：38.10dBi@12.50GHz |
|
TX：39.30dBi@14.25GHz |
|
|
Cross pollsolation |
≥30dB |
|
Polarization |
linear |
|
Tracking Accuracy |
≤0.2°RMS |
|
Carrier Motion Range |
Roll：-30°~30° |
|
Pitch：-30°~30° |
|
|
Antenna Motion Range |
Azimuth：360°continuous rotation |
|
Elevation：-10°～110° |
|
|
Roll: -30°～30° |
|
|
Polarization: 0°～270° |
|
|
Initial Acquisition time |
≤180s |
|
Tracking mode |
INS measurement and carrier tracking |
|
Input Power |
DC 24V/AC 110~240V peak power consumption 120W（BUC excluded） |
|
Operating Temperature |
-20℃～60℃ |
